cAP LTE12 ax

A powerful ceiling access point that offers true Wi-Fi 6 mobility for your outdoor business - now with a CAT12 LTE modem!

Зацікавив пристрій?

cAP LTE12 ax

When it comes to providing reliable wireless connectivity in busy business environments, you need a solution that is both powerful and discreet. Whether you’re running an open-air pop-up store, a festival food stand, or a cozy coffee shop in the park, you need a device that can withstand the challenges of busy, high-traffic areas. You need cAP LTE12 ax – with its fast, reliable mobile internet and incredible Wi-Fi 6 coverage for you and your clients!

Elevate Your Connectivity:
Literally and Figuratively

In bustling high-traffic spaces, traditional access points can face numerous obstacles - devices get knocked over, misplaced, or even stolen. The cAP offers a simple yet effective solution: mount your access point on the ceiling. Not only does this method physically elevate the device, but it also ensures optimal signal distribution, minimizes interference from obstacles, and reduces the risk of theft. Also, you’ll have fewer cables and devices in your workspace to worry about – it’s a win-win scenario!

More Than Just an Access Point

With a powerful quad-core ARM CPU running at 1.8 GHz, a gigabyte of RAM, and the extremely flexible RouterOS v7 at its core, the cAP LTE12 ax is far more than just a simple access point. It offers a range of advanced features, including:

  • Complex firewall rules
  • IPsec hardware encryption and Wireguard support
  • Advanced routing and multiple VPN tunnels
  • Support for remote work and file-sharing
  • Even some light BGP action!

This makes it an ideal solution for businesses that require secure, high-performance mobile connectivity in challenging environments.

Unstoppable 802.11ax (Wi-Fi 6) Radio and Improved Security

With Wi-Fi 6, you can utilize the full potential of the speedy CAT12 600 Mbps LTE modem. We’re looking at up to 40% higher speed in the 5 GHz spectrum and up to 90% higher speed in the 2.4 GHz spectrum compared to previous generations. Additionally, Wi-Fi 6 offers significantly improved energy efficiency and security with OWE/WPA3-PSK/WPA3-EAP encryption and management frame protection. These features help prevent attacks like brute-forcing and deauthentication.

If you have multiple access points over a larger area, you’ll enjoy the improved seamless fast transition roaming – your devices will switch to the strongest signal... seamlessly!

PoE and Effortless Management

The cAP ax makes your office network installation and maintenance easier with PoE-in and PoE-out. That’s right – you can use cAP ax to power other devices, such as network switches, CCTV cameras, or even another cAP ax! And, speaking of easy office networks... Just a few clicks in our latest wifi-qcom CAPsMAN central management system - and you’re done setting up hundreds of cAP ax devices! You can use all sorts of MikroTik devices to run CAPsMAN effortlessly, for example - your main gateway.

Specifications

Product code cAPGi-5HaxD2HaxD&EG12-EA
Architecture ARM 64bit
CPU IPQ-6010
CPU core count 4
CPU nominal frequency auto (864 - 1800) MHz
Switch chip model IPQ-6010
RouterOS license 4
Operating System RouterOS v7
Size of RAM 1 GB
Storage size 128 MB
Storage type NAND
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -40°C to 50°C
IPsec hardware acceleration Yes

Powering

Number of DC inputs 2 (DC jack, PoE-IN)
DC jack input Voltage 18-57 V
Max power consumption 34 W
Max power consumption without attachments 13 W
Cooling type Passive
PoE in 802.3af/at
PoE in input Voltage 18-57 V

PoE-out

PoE-out ports Ether2
PoE out Passive PoE up to 57V
Max out per port output (input 18-30 V) 0.6 A
Max out per port output (input 30-57 V) 0.4 A
Max total out (A) 0.6 A
Total output current 0.6
Total output power 22.8

Mobile

3G Category R8 (42.2Mbps Downlink, 11.2Mbps Uplink)
3G bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz)
LTE Category 12 (600Mbps Downlink, 150Mbps Uplink)
MIMO DL 4x4
MIMO UL 1x1
LTE FDD bands 1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) / 28 (700MHz)
LTE TDD bands 38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz)
TAC 86056104

Wireless specifications

Wireless 2.4 GHz Max data rate 574 Mbit/s
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n/ax
Antenna gain dBi for 2.4 GHz 6
Wireless 2.4 GHz chip model QCN-5022
Wireless 2.4 GHz generation Wi-Fi 6
Wireless 5 GHz Max data rate 1200 Mbit/s
Wireless 5 GHz number of chains 2
Wireless 5 GHz standards 802.11a/n/ac/ax
Antenna gain dBi for 5 GHz 5.5
Wireless 5 GHz chip model QCN-5022
Wireless 5 GHz generation Wi-Fi 6

Ethernet

10/100/1000 Ethernet ports 2
Number of 1G Ethernet ports with PoE-out 1

Peripherals

Number of SIM slots 1 Modem (Micro SIM)

Other

CPU temperature monitor Yes
Mode button Yes

Certification & Approvals

Certification CE, EAC, ROHS
IP 20
Brochure Перейти
User manual Перейти
RouterOS current release Перейти
Safety and regulatory information Перейти
RouterOS software manual Перейти
Declaration of conformity Перейти

Ethernet test results

cAPGi-5HaxD2HaxD&EG12-EAIPQ-6010 2-port test
ModeConfiguration1518 byte512 byte64 byte
kppsMbpskppsMbpskppsMbps
Bridgingnone (fast path)162.51974469.91924.81470.1799.7
Bridging25 bridge filter rules162.51974380.11556.9386.5210.2
Routingnone (fast path)162.51974469.91924.81281.6697.2
Routing25 simple queues162.51973.13911601.7395.2215
Routing25 ip filter rules162.51973.1266.71092.5268.7146.2
  1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
  2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
  3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

IPsec test results

cAPGi-5HaxD2HaxD&EG12-EAIPQ-6010 IPsec throughput
ModeConfiguration1400 byte512 byte64 byte
kppsMbpskppsMbpskppsMbps
Single tunnelAES-128-CBC + SHA178.4878.191.9376.493.647.9
256 tunnelsAES-128-CBC + SHA150.1561.155.5227.358.630
256 tunnelsAES-128-CBC + SHA2565056055.4226.958.630
256 tunnelsAES-256-CBC + SHA149.4553.354.8224.558.630
256 tunnelsAES-256-CBC + SHA25649.4553.355225.358.630
  1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
  2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1400 byte packet sizes
  3. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
